Product display:
Geosynthetic Clay Liner is a kind of synthetic material specially used for anti-seepage of artificial lakes, landfills, underground garages, roof gardens, pools, oil depots and chemical storage yards. The sodium-based bentonite is filled between the special composite geotextile and non-woven fabric, and the bentonite impermeable pad made by acupuncture method can form many small fiber spaces, so that the bentonite particles cannot flow in one direction, and the pad is in contact with water. A uniform and high-density colloidal waterproof layer is formed inside, which can effectively prevent water leakage. GCL is a kind of anti-seepage liner between GCL (on-site thick compacted clay anti-seepage liner) and polymer material - geomembrane, with good effect and strong damage resistance.
Features:
1. It has excellent waterproof and anti-seepage performance, the anti-seepage hydrostatic pressure can reach more than 1.0MPa, the permeability is 5×10-11m/s, and the mass of bentonite per unit area is 5000g/m2. Bentonite is a natural inorganic material and will not undergo aging reaction. , good durability; and will not cause any adverse impact on the environment is an environmentally friendly material
2. It has all the characteristics of geotextile materials, such as separation, reinforcement, protection, filtration, etc. The construction is simple and not limited by the construction environment temperature, and it can also be constructed below 0 °C. During construction, simply lay the GCL waterproof blanket on the ground, fix it with nails and washers, and lap it as required.
3. Easy to repair; even after the waterproof (seepage) construction is completed, if the waterproof layer is accidentally damaged, as long as the damaged parts are simply repaired, the original waterproof performance can be regained.
4. The performance-price ratio is relatively high, and the use is very extensive.
5. The width of the product can reach 6 meters, which matches the specifications of the international geotextile (membrane), which greatly improves the construction efficiency.
Product Usage:
Municipal (garbage reclamation), water conservancy, environmental protection, artificial lakes, tunnels, subways, basements, underground passages and underground waterproofing and anti-seepage projects of various buildings.
